News







Main Center stand
Honda CBX 1000 1978-1979-1980
Order
 here



New Carburetor screw kit

order them now

61 carburetor Screws and 6 piece Drain Screw including "O"ring New :
Complete kit to make your carbs like new, one of the finest brands around for doing a carburetor rebuild job.
This kit will fit in Honda cbx 1000 1978>1983













we have at this moment 60% of our parts stock in the webshop, we are working on an update, if you are looking for a part that is not in the Web shop are please send an email








 New videos on youtube !!

The long tensioner A cam 14510-422-010 is no longer available at Honda.
We now have  the solution. If you send us the old one, we will put a new blade on it and will galvanise the metal part.
order here








New oversized rubbers to keep the noise out of you CB1 basket , order them in our web shop




OVERSIZED RUBERS INSTAL INSTUCTION






OVERSIZED RUBERS INSTAL INSTUCTION Honda CBX 1000 Z & A type


#1 - Grind off the rivet heads

#2 - With center punch and hammer, punch the existing rivets down just enough to remove the cover plate

#3 - File sharp edges off rivets, then press them out with a small 5mm punch

#4 - clean all parts and disassembled parts together

#5 - Enlarge holes in the steel cover plate with a 6.0mm drill

#6 – You do not have drill the aloy existing holes , Thread existing holes with an M6 tap

#7 - Install the new rubber dampers

#8 - Lightly grease the holes at the big gear and the rubbers

#9 - Apply Loctite (medium strength blue) inside the tapped holes, or on the bolts

#10 - Use M6 x 25mm buttonhead flange bolts File heads to a maximum height of 1.7mm if necessary.

#11 - Center punch the back side of the bolts to secure

#12 - Assembled clutch basket, ready to install
